Original: $549.10
-70%$549.10
$164.73The Story
SPECIFICATION
|
Name |
AMD Ryzen™ 7 9800X3D |
|
Family |
Ryzen |
|
Series |
Ryzen 9000 Series |
|
Form Factor |
Desktops, Boxed Processor |
|
Market Segment |
Enthusiast Desktop |
|
AMD PRO Technologies |
No |
|
Consumer Use |
Yes |
|
Regional Availability |
Global |
|
Former Codename |
Granite Ridge AM5 |
|
Architecture |
Zen 5 |
|
# of CPU Cores |
8 |
|
Multithreading (SMT) |
Yes |
|
# of Threads |
16 |
|
Max. Boost Clock |
Up to 5.2 GHz |
|
Base Clock |
4.7 GHz |
|
L1 Cache |
640 KB |
|
L2 Cache |
8 MB |
|
L3 Cache |
96 MB |
|
Default TDP |
120W |
|
Processor Technology for CPU Cores |
TSMC 4nm FinFET |
|
Processor Technology for I/O Die |
TSMC 6nm FinFET |
|
Package Die Count |
2 |
|
Unlocked for Overclocking |
Yes |
|
AMD EXPO™ Memory Overclocking Technology |
Yes |
|
Precision Boost Overdrive |
Yes |
|
Curve Optimizer Voltage Offsets |
Yes |
|
AMD Ryzen™ Master Support |
Yes |
|
CPU Socket |
AM5 |
|
Supporting Chipsets |
A620, X670E, X670, B650E, B650, X870E, X870, B840, B850 |
|
CPU Boost Technology |
Precision Boost 2 |
|
Instruction Set |
x86-64 |
|
Supported Extensions |
AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
|
Thermal Solution (PIB) |
Not Included |
|
Recommended Cooler |
Liquid cooler recommended for optimal performance |
|
Max. Operating Temperature (Tjmax) |
95°C |
|
Launch Date |
11/07/2024 |
|
OS Support |
Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit |
|
Connectivity |
Native USB 3.2 Gen 2 (10Gbps) Ports: 4, Native USB 2.0 (480Mbps) Ports: 1 |
|
PCI Express® Version |
PCIe® 5.0 |
|
Native PCIe® Lanes (Total/Usable) |
28 / 24 |
|
NVMe Support |
Boot, RAID0, RAID1, RAID5, RAID10 |
|
System Memory Type |
DDR5 |
|
Memory Channels |
2 |
|
Max. Memory |
192 GB |
|
System Memory Subtype |
UDIMM |
