SPECIFICATION
|
Model name |
24G15N |
|
Panel |
23.8" (VA) |
|
Pixel Pitch (mm) |
0.2745 (H) × 0.2745 (V) |
|
Effective Viewing Area (mm) |
527.04 (H) × 296.46 (V) |
|
Brightness (typical) |
250 cd/m² |
|
Contrast Ratio |
4000 : 1 (Typical) 80 Million : 1 (DCR) |
|
Response Time |
1ms (MPRT) / 4ms (GtG) |
|
Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
|
Color Gamut |
sRGB 100% (CIE1931) / DCI-P3 89% (CIE1976) |
|
Color Accuracy |
Delta E < 2 |
|
Optimum Resolution |
1920 × 1080 @ 180Hz – DisplayPort, HDMI |
|
Display Colors |
16.7 Million |
|
Signal Input |
HDMI 2.0 x 1, DisplayPort 1.4 x 1 |
|
HDCP Version |
HDMI: 2.2, DisplayPort: 2.2 |
|
USB Hub |
no |
|
Power Supply |
External 19VDC, 1.31A |
|
Power Consumption (typical) |
22W |
|
Speakers |
no |
|
Line in & Earphone |
Earphone |
|
Wall-Mount |
100mm × 100mm |
|
Adjustable Stand |
Tilt: -5° ~ 18° |
|
Product without Stand (mm) |
320.8 (H) × 539.7 (W) × 49.1 (D) |
|
Product with Stand (mm) |
423.5 (H) × 539.7 (W) × 178.6 (D) |
|
Packaging (mm) |
396 (H) × 603 (W) × 130 (D) |
|
Product without Stand (kg) |
2.80 |
|
Product with Stand (kg) |
3.13 |
|
Product with Packaging (kg) |
4.26 |
|
Cabinet Color |
Black |
