SPECIFICATION
|
Model name |
24G2SPE |
|
Panel |
23.8" (IPS) |
|
Pixel Pitch (mm) |
0.2745 (H) × 0.2745 (V) |
|
Effective Viewing Area (mm) |
527.04 (H) × 296.46 (V) |
|
Brightness (typical) |
300 cd/m² |
|
Contrast Ratio |
1100 : 1 (Typical) 80 Million : 1 (DCR) |
|
Response Time |
1ms (MPRT) /4ms (GtG) |
|
Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
|
Color Gamut |
NTSC 96% (CIE1976) / sRGB 125% (CIE1931) / DCI-P3 87% (CIE1976) |
|
Color Accuracy |
Delta E < 2 |
|
Optimum Resolution |
1920 × 1080 @ 165Hz – DisplayPort; 1920 × 1080 @ 144Hz – HDMI; 1920 × 1080 @ 60Hz – VGA |
|
Display Colors |
16.7 Million |
|
Signal Input |
VGA × 1, HDMI 1.4 × 2, DisplayPort 1.2 × 1 |
|
HDCP Version |
HDMI :1.4 / DisplayPort :1.4 |
|
USB Hub |
no |
|
Power Supply |
100 - 240V?1.5A, 50 / 60Hz |
|
Power Consumption (typical) |
22W |
|
Speakers |
no |
|
Line in & Earphone |
Earphone |
|
Wall-Mount |
100 x 100mm |
|
Adjustable Stand |
Tilt: -5° ~ 23° |
|
Product without Stand (mm) |
322.1 (H) × 539.05 (W) × 47.2 (D) |
|
Product with Stand (mm) |
421 (H) × 539.05 (W) × 227.4 (D) |
|
Product without Stand (kg) |
2.82 |
|
Product with Stand (kg) |
3.75 |
|
Cabinet Color |
Black & Red |
|
Regulatory Approvals |
BSMI / KC / KCC / e-Standby / RCM / MEPS / CE / CB / FCC |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
SPECIFICATION
|
Model name |
24G2SPE |
|
Panel |
23.8" (IPS) |
|
Pixel Pitch (mm) |
0.2745 (H) × 0.2745 (V) |
|
Effective Viewing Area (mm) |
527.04 (H) × 296.46 (V) |
|
Brightness (typical) |
300 cd/m² |
|
Contrast Ratio |
1100 : 1 (Typical) 80 Million : 1 (DCR) |
|
Response Time |
1ms (MPRT) /4ms (GtG) |
|
Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
|
Color Gamut |
NTSC 96% (CIE1976) / sRGB 125% (CIE1931) / DCI-P3 87% (CIE1976) |
|
Color Accuracy |
Delta E < 2 |
|
Optimum Resolution |
1920 × 1080 @ 165Hz – DisplayPort; 1920 × 1080 @ 144Hz – HDMI; 1920 × 1080 @ 60Hz – VGA |
|
Display Colors |
16.7 Million |
|
Signal Input |
VGA × 1, HDMI 1.4 × 2, DisplayPort 1.2 × 1 |
|
HDCP Version |
HDMI :1.4 / DisplayPort :1.4 |
|
USB Hub |
no |
|
Power Supply |
100 - 240V?1.5A, 50 / 60Hz |
|
Power Consumption (typical) |
22W |
|
Speakers |
no |
|
Line in & Earphone |
Earphone |
|
Wall-Mount |
100 x 100mm |
|
Adjustable Stand |
Tilt: -5° ~ 23° |
|
Product without Stand (mm) |
322.1 (H) × 539.05 (W) × 47.2 (D) |
|
Product with Stand (mm) |
421 (H) × 539.05 (W) × 227.4 (D) |
|
Product without Stand (kg) |
2.82 |
|
Product with Stand (kg) |
3.75 |
|
Cabinet Color |
Black & Red |
|
Regulatory Approvals |
BSMI / KC / KCC / e-Standby / RCM / MEPS / CE / CB / FCC |
