SPECIFICATION
|
Model |
ASUS RT-BE92U |
|
Network Standard |
IEEE 802.11a/b/g; WiFi 4 (802.11n); WiFi 5 (802.11ac); WiFi 6 (802.11ax); WiFi 6E (802.11ax); WiFi 7 (802.11be); IPv4; IPv6 |
|
Product Segment |
BE9700 ultimate BE performance: 1032 + 2882 + 5764 Mbps |
|
WiFi Data Rate |
WiFi 7 (2.4GHz): up to 1032 Mbps; WiFi 7 (5GHz): up to 2882 Mbps; WiFi 7 (6GHz): up to 5764 Mbps |
|
Antenna |
External antenna ×4 |
|
Transmit / Receive |
2.4GHz 3x3; 5GHz 2x2; 6GHz 2x2 |
|
Processor |
2.0GHz quad-core processor |
|
Memory |
256 MB Flash; 1 GB DDR4 RAM |
|
Boosts Speed |
OFDMA; Beamforming (standard-based & universal); 4096-QAM; 20/40/80/160/320 MHz bandwidth |
|
Operating Frequency |
2.4 GHz; 5 GHz; 6 GHz |
|
Operating Mode |
Wireless Router Mode; AiMesh Node Mode; Access Point Mode; Media Bridge Mode; Repeater Mode |
|
I/O Ports |
1 × 10Gbps WAN/LAN; 1 × 2.5Gbps WAN/LAN; 3 × 2.5Gbps LAN; USB 3.2 Gen1 ×1 |
|
Buttons |
WPS Button; Reset Button; Power Switch |
|
LED Indicator |
Power ×1; WAN ×1; LAN ×1; 2.4GHz ×1; 5GHz ×1; 6GHz ×1 |
|
Power Supply |
AC Input: 110V–240V (50–60Hz); DC Output: 12V max 3A |
|
Package Content |
RT-BE92U WiFi 7 Tri-band Router; Wall Mount Kit; RJ-45 cable; Power Adapter; Quick Start Guide; Warranty Card |
|
Product Dimensions |
247.18 × 101.59 × 287.47 mm (9.73 × 4.00 × 11.32 inch) |
|
AiMesh |
Primary AiMesh Router; AiMesh Node |
|
Parental Control |
Web & Apps Filters; Time Scheduling; Safe Browsing; Customized Internet Schedule; Max Profiles: 64 |
|
Guest Network |
Supports Guest Network; Max Rules: 2.4GHz + 5GHz (3); Encryption: Open System, WPA/WPA2/WPA3-Personal |
|
Security |
AiProtection; VPN; WPA/WPA2/WPA3 Personal; WPA/WPA2/WPA3 Enterprise; Open System & OWE; WPS; Let's Encrypt; DNS-over-TLS; SSH; Security Scan; Firewall (Keyword: 64 / Network Service: 32 / URL: 64) |
|
AiProtection |
Router Security Assessment; Malicious Site Blocking; Two-Way IPS |
|
VPN |
Instant Guard; VPN Client (L2TP, OpenVPN, PPTP, WireGuard); VPN Server (IPSec, OpenVPN, PPTP, WireGuard); VPN Fusion; Support Surfshark |
|
Traffic Control |
Adaptive QoS (Bandwidth Monitor; Bandwidth Limiter max 32 rules); Traditional QoS; Traffic Monitor (Real-time/Wired/Wireless); Traffic Analyzer (Daily/Weekly/Monthly; Website History) |
|
WAN |
PPPoE; PPTP; L2TP; Automatic IP; Static IP; IPSec; Dual WAN; 3G/4G LTE Dongle; 4G/5G Mobile Tethering; Port Forwarding (64); Port Triggering (32); DMZ; DDNS; NAT Passthrough (PPTP/L2TP/IPSec/RTSP/H.323/SIP/PPPoE Relay) |
|
LAN |
DHCP Server; IGMP Snooping; IPTV; Manual IP Assignment (128 rules); Wake on LAN (WOL) |
|
Wireless |
MU-MIMO; UTF-8 SSID; MAC Filter (64); Wireless Scheduler; Airtime Fairness; RADIUS Client; Universal & Explicit Beamforming |
|
USB Application |
4G/5G Mobile Tethering; File System (HFS+, NTFS, vFAT, ext2/3/4); Safely Remove Disk; Download Master; Media Server; Time Machine; Samba Server; FTP Server; Shared Folder Privileges |
|
User Interface |
WEB: ASUSWRT; APP: ASUS Router APP |
|
Administration |
Configuration Backup & Restore; Diagnosis Tools; Feedback System; System Log; New Device Notification; Login Captcha; Connection Diagnosis; Auto Firmware Update |
