SPECIFICATION
|
Power |
100W |
|
Cell Type |
Monocrystalline Silicon |
|
Cell Lamination |
ETFE (Ethylene tetrafluoroethylene) |
|
Cell Efficiency |
Up to 23.4% |
|
Voltage at Max Power (Vmp) |
18.8V |
|
Current at Max Power (Imp) |
5.3Aa |
|
Open Circuit Voltage (OCV) |
23.7V |
|
Short Circuit Current (Isc) |
5.8A |
|
Connector |
Standard MC4 Connector |
|
Folding Design |
4 Folds |
|
Weight |
12.57 lbs / 5.7 kg |
|
Dimensions (Folded) |
20.7 × 20.5 × 2.5 in / 525 × 520 × 65 mm |
|
Dimensions (Unfolded) |
20.7 × 89.2 in / 525 × 2265 mm |
|
Operating Temperature |
14–149 °F (-10~65 °C) |
|
Best Working Temperature |
77 °F (25 °C) |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
SPECIFICATION
|
Power |
100W |
|
Cell Type |
Monocrystalline Silicon |
|
Cell Lamination |
ETFE (Ethylene tetrafluoroethylene) |
|
Cell Efficiency |
Up to 23.4% |
|
Voltage at Max Power (Vmp) |
18.8V |
|
Current at Max Power (Imp) |
5.3Aa |
|
Open Circuit Voltage (OCV) |
23.7V |
|
Short Circuit Current (Isc) |
5.8A |
|
Connector |
Standard MC4 Connector |
|
Folding Design |
4 Folds |
|
Weight |
12.57 lbs / 5.7 kg |
|
Dimensions (Folded) |
20.7 × 20.5 × 2.5 in / 525 × 520 × 65 mm |
|
Dimensions (Unfolded) |
20.7 × 89.2 in / 525 × 2265 mm |
|
Operating Temperature |
14–149 °F (-10~65 °C) |
|
Best Working Temperature |
77 °F (25 °C) |
