The Story
SPECIFICATION
|
POWER |
|
|
Power |
350W |
|
Lamination |
ETFE (Ethylene tetrafluoroethylene) |
|
Cell Type |
Monocrystalline Silicon |
|
Cell Efficiency |
Up to 23.4% |
|
Voltage at Max Power (Vmp) |
37.5V |
|
Current at Max Power (Imp) |
9.2A |
|
Open Circuit Voltage (OCV) |
47V |
|
Short Circuit Current (Isc) |
10.8A |
|
GENERAL |
|
|
Connector |
Standard MC4 Connector |
|
Weight |
34.8lbs (15.8kg) |
|
Dimensions (Unfolded) |
36.5 × 93.3in (92.8 × 237.2cm) |
|
Dimension (Folded) |
36.5 × 23.3 × 2.5in (92.8 × 59.3 × 6.5cm) |
|
Operating Temperature |
14–149℉ (-10–65℃) |
|
Best Working Temperature |
77℉ (25℃) |
|
Cable Length |
118in (3m) |
|
Certifications |
FCC, CE, ROHS |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
SPECIFICATION
|
POWER |
|
|
Power |
350W |
|
Lamination |
ETFE (Ethylene tetrafluoroethylene) |
|
Cell Type |
Monocrystalline Silicon |
|
Cell Efficiency |
Up to 23.4% |
|
Voltage at Max Power (Vmp) |
37.5V |
|
Current at Max Power (Imp) |
9.2A |
|
Open Circuit Voltage (OCV) |
47V |
|
Short Circuit Current (Isc) |
10.8A |
|
GENERAL |
|
|
Connector |
Standard MC4 Connector |
|
Weight |
34.8lbs (15.8kg) |
|
Dimensions (Unfolded) |
36.5 × 93.3in (92.8 × 237.2cm) |
|
Dimension (Folded) |
36.5 × 23.3 × 2.5in (92.8 × 59.3 × 6.5cm) |
|
Operating Temperature |
14–149℉ (-10–65℃) |
|
Best Working Temperature |
77℉ (25℃) |
|
Cable Length |
118in (3m) |
|
Certifications |
FCC, CE, ROHS |
