The Story
SPECIFICATION
|
Part Number |
57NON7MDBROC |
|
Product Name |
GALAX GeForce RTX™ 5070 1-Click OC |
|
Memory |
12 GB GDDR7 |
|
Memory Interface Width |
192-bit |
|
Display Outputs |
3 × DisplayPort 2.1b, 1 × HDMI 2.1b |
|
DLSS Version |
NVIDIA DLSS 4 |
|
Architecture |
NVIDIA Blackwell, RTX 50 Series |
|
Product Code |
57NON7MDBROC |
|
EAN |
4895147158600 |
|
Driver Download |
Available |
|
High-Res Photo |
Available |
|
1-Click OC Support |
Yes (via Xtreme Tuner Plus for PC/Android/iOS) |
|
Awards |
Gold Award (Game2gether, Germany), Design Award (What Next, Poland) |
|
GPU Engine Specs – CUDA Cores |
6,144 |
|
GPU Engine Specs – Boost Clock |
2,527 MHz |
|
GPU Engine Specs – 1-Click OC Clock |
2,542 MHz (via Xtreme Tuner Plus) |
|
Memory Specs – Speed |
28 Gbps |
|
Memory Specs – Bandwidth |
672 GB/sec |
|
Feature Support – PCI Express |
PCI-E 5.0 |
|
Feature Support – OS Compatibility |
Windows 10/11 64-bit |
|
Fan Feature – Fans |
2 × 92 mm |
|
Fan Feature – Technology |
WINGS 3.0 with Fan Stop |
|
Display Support – DisplayPort |
3 × DisplayPort 2.1b |
|
Display Support – HDMI |
1 × HDMI 2.1b |
|
Dimensions – With Bracket |
252 × 131 × 40.6 mm |
|
Dimensions – Without Bracket |
240 × 115.5 × 39.6 mm (NVIDIA SFF-Ready) |
|
In-Box Accessories |
PCIe 1 × 16-pin to 2 × 8-pin adapter |
