SPECIFICATION
|
Part Number |
N506T2-16D7-191073N |
|
CUDA Cores |
4608 |
|
Boost Clock |
2572 MHz |
|
Base Clock |
2407 MHz |
|
Minimum System Power |
650 W |
|
Supplementary Power |
1× PCIe 8-pin |
|
Memory Clock |
28 Gbps |
|
Memory Capacity |
16 GB |
|
Memory Type |
GDDR7 |
|
Memory Bus Width |
128-bit |
|
Memory Bandwidth |
448 GB/s |
|
Real-Time Ray Tracing |
Yes |
|
RT Cores |
4th Gen (72 TFLOPS) |
|
Tensor Cores |
5th Gen (759 AI TOPS) |
|
Architecture |
NVIDIA Blackwell |
|
DirectX |
12 Ultimate |
|
DLSS |
4 |
|
Ansel / FreeStyle / Highlights |
Yes / Yes / Yes |
|
ShadowPlay |
Yes |
|
Bus Support |
PCIe Gen 5 |
|
OS Certification |
Windows 11/10, Linux, FreeBSD x86 |
|
Game-Ready / Studio Drivers |
Yes / Yes |
|
GPU Boost |
Yes |
|
Vulkan / OpenGL |
1.4 / 4.6 |
|
Encoder / Decoder |
1× 9th Gen / 1× 6th Gen |
|
Card Dimensions |
250 mm (L) × 116 mm (H) × 41 mm (W) |
|
Display Support |
Up to 4 monitors; 4K 480 Hz or 8K 165 Hz w/ DSC |
|
HDCP Version |
2.3 |
|
Display Connectors |
3× DisplayPort 2.1b, 1× HDMI 2.1b |
