INNO3D GeForce RTX™ 5060 Ti TWIN X2 OC 16GB GDDR7 128-bit Graphics Card

Part Number

GPU Engine Specs

CUDA Cores

4608

Boost Clock

2602 MHz

Base Clock

2235 MHz

Thermal and Power Spec

Minimum System Power Requirement

650W

Supplementary Power Connectors

1x PCIe 8-pin cable

Memory Specs

Memory Clock

28 Gbps

Standard Memory Config

16GB

Memory Interface

GDDR7

Memory Interface Width

128-bit

Memory Bandwidth

448 GB/sec

Feature Support

Real-Time Ray Tracing

Yes

Ray Tracing Cores

4th Generation, 72 TFLOPS

Tensor Cores

5th Generation, 759 AI TOPS

NVIDIA Architecture

Blackwell

Microsoft DirectX

12 Ultimate

NVIDIA DLSS

4

NVIDIA Ansel

Yes

NVIDIA FreeStyle

Yes

Bus Support

PCI Express Gen 5

NVIDIA ShadowPlay

Yes

OS Certification

Windows 11 / 10, Linux, FreeBSDx86

NVIDIA Highlights

Yes

NVIDIA G-SYNC™-Ready

Yes

Game Ready Drivers

Yes

NVIDIA Studio Drivers

Yes

NVIDIA GPU Boost™

Yes

Vulkan API

1.4

OpenGL

4.6

NVIDIA Encoder

1x Ninth Generation

NVIDIA Decoder

1x Sixth Generation

Accessories

Graphics Card Dimensions

Length: 250mm, Height: 116mm, Width: 41mm

Display Support

Multi Monitor Support

Up to 4

Maximum Digital Resolution

4K at 480Hz or 8K at 165Hz with DSC

HDCP

2.3

Standard Display Connectors

3x DisplayPort 2.1b, 1x HDMI 2.1b
