SPECIFICATION
|
CUDA Cores |
21760 |
|
Boost Clock (MHz) |
2407 MHz |
|
Base Clock (MHz) |
2017 MHz |
|
Minimum System Power Requirement (W) |
1000W |
|
Supplementary Power Connectors |
4x PCIe 8-pin cables (adapter in box) OR 1x 600W PCIe Gen 5 cable |
|
Memory Clock |
28 Gbps |
|
Standard Memory Config |
32GB GDDR7 |
|
Memory Interface |
GDDR7 |
|
Memory Interface Width |
512-bit |
|
Memory Bandwidth (GB/sec) |
1792 GB/sec |
|
Real-Time Ray Tracing |
Yes |
|
Ray Tracing Cores |
4th Generation, 318 TFLOPS |
|
Tensor Cores |
5th Generation, 3352 AI TOPS |
|
NVIDIA Architecture |
Blackwell |
|
Microsoft DirectX |
12 Ultimate |
|
NVIDIA DLSS |
4 |
|
NVIDIA Ansel |
Yes |
|
NVIDIA FreeStyle |
Yes |
|
Bus Support |
PCI Express Gen 5 |
|
NVIDIA ShadowPlay |
Yes |
|
OS Certification |
Windows 11 / 10, Linux, FreeBSD x86 |
|
NVIDIA Highlights |
Yes |
|
NVIDIA G-SYNC™-Ready |
Yes |
|
Game Ready Drivers |
Yes |
|
NVIDIA Studio Drivers |
Yes |
|
NVIDIA GPU Boost™ |
Yes |
|
Vulkan API |
1.4 |
|
OpenGL |
4.6 |
|
NVIDIA Encoder |
3x Ninth Generation |
|
NVIDIA Decoder |
2x Sixth Generation |
|
Graphics Card Stand |
Yes (embedded with cooler) |
|
Graphics Card Dimensions (mm) |
Length: 333, Height: 137, Width: 60 |
|
Display Support |
Multi Monitor, up to 4 |
|
Maximum Digital Resolution |
4K at 480Hz or 8K at 165Hz with DSC |
|
HDCP |
2.3 |
|
Standard Display Connectors |
3x DisplayPort 2.1b, 1x HDMI 2.1b |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
SPECIFICATION
|
CUDA Cores |
21760 |
|
Boost Clock (MHz) |
2407 MHz |
|
Base Clock (MHz) |
2017 MHz |
|
Minimum System Power Requirement (W) |
1000W |
|
Supplementary Power Connectors |
4x PCIe 8-pin cables (adapter in box) OR 1x 600W PCIe Gen 5 cable |
|
Memory Clock |
28 Gbps |
|
Standard Memory Config |
32GB GDDR7 |
|
Memory Interface |
GDDR7 |
|
Memory Interface Width |
512-bit |
|
Memory Bandwidth (GB/sec) |
1792 GB/sec |
|
Real-Time Ray Tracing |
Yes |
|
Ray Tracing Cores |
4th Generation, 318 TFLOPS |
|
Tensor Cores |
5th Generation, 3352 AI TOPS |
|
NVIDIA Architecture |
Blackwell |
|
Microsoft DirectX |
12 Ultimate |
|
NVIDIA DLSS |
4 |
|
NVIDIA Ansel |
Yes |
|
NVIDIA FreeStyle |
Yes |
|
Bus Support |
PCI Express Gen 5 |
|
NVIDIA ShadowPlay |
Yes |
|
OS Certification |
Windows 11 / 10, Linux, FreeBSD x86 |
|
NVIDIA Highlights |
Yes |
|
NVIDIA G-SYNC™-Ready |
Yes |
|
Game Ready Drivers |
Yes |
|
NVIDIA Studio Drivers |
Yes |
|
NVIDIA GPU Boost™ |
Yes |
|
Vulkan API |
1.4 |
|
OpenGL |
4.6 |
|
NVIDIA Encoder |
3x Ninth Generation |
|
NVIDIA Decoder |
2x Sixth Generation |
|
Graphics Card Stand |
Yes (embedded with cooler) |
|
Graphics Card Dimensions (mm) |
Length: 333, Height: 137, Width: 60 |
|
Display Support |
Multi Monitor, up to 4 |
|
Maximum Digital Resolution |
4K at 480Hz or 8K at 165Hz with DSC |
|
HDCP |
2.3 |
|
Standard Display Connectors |
3x DisplayPort 2.1b, 1x HDMI 2.1b |
