SPECIFICATION
|
Panel Size |
23.6" (60 cm) |
|
Active Display Area (mm) |
521.395 (H) x 293.284 (V) |
|
Curvature |
1500R |
|
Panel Type |
VA |
|
Panel Resolution |
1920 x 1080 (FHD) |
|
Pixel Pitch (H x V) |
0.27156 (H) x 0.27156 (V) |
|
Aspect Ratio |
16:9 |
|
Brightness (nits) |
250 |
|
Contrast Ratio |
3000:1 |
|
DCR |
100000000:1 |
|
Signal Frequency |
55.3 |
|
Refresh Rate |
180 Hz |
|
Response Time |
1ms (MPRT) |
|
Dynamic Refresh Rate Technology |
Adaptive sync |
|
Video Ports |
2x HDMI™ (Supports 1920 x 1080 @180Hz per HDMI™ 2.0b), 1x DP (Supports 1920 x 1080 @180Hz per DisplayPort 1.2a) |
|
Audio Ports |
1x Earphone out |
|
Viewing Angle |
178° (H) / 178° (V) |
|
Adobe RGB / DCI-P3 / sRGB |
88% / 89% / 112% |
|
Surface Treatment |
Anti-glare |
|
Display Colors |
16.7M |
|
Frameless Design |
Yes |
|
Power Type |
External Adaptor 20V 2.25A |
|
Power Input |
100~240V |
|
Adjustment (Tilt) |
-5° ~ 20° |
|
Kensington Lock |
Yes |
|
VESA Mounting |
100 x 100 mm |
|
Weight (NW / GW) |
3.5 kg / 5.2 kg (2.8 kg without stand) |
|
Dimension (W x D x H) |
537 x 225 x 429 mm (537 x 68 x 326 mm without stand) |
|
Carton Dimension (W x D x H) |
WW: 606 x 172 x 409 mm, Outer: 621 x 187 x 434 mm |
|
Note |
Display Port: 1920 x 1080 (Up to 180Hz); HDMI: 1920 x 1080 (Up to 180Hz); *Adobe RGB, sRGB and DCI-P3 follow CIE1976 standard |
