The Story
SPECIFICATION
|
Number of Fans |
1 |
|
Fan Dimensions |
120 x 120 x 25 mm / 4.7 x 4.7 x 0.98 inches |
|
Fan Speed |
510~2070 RPM ± 200 RPM (10%) |
|
Fan Air Flow |
62.6 CFM |
|
Fan Noise Level |
30.11 dBA (MAX 34.1) |
|
Fan Static Pressure |
2.36 mmH₂O |
|
Fan Bearing |
Rifle Bearing |
|
Fan Life Expectancy |
40,000 hrs @ 40℃ |
|
Fan Rated Current |
0.15A (Max: 0.18A) |
|
Fan Power Consumption |
1.44W (Max: 2.16W) |
|
PWM Mode |
Yes |
|
Cable Length (5V ARGB / PWM cable) |
300mm |
|
Fan Lighting |
ARGB GEN1 |
|
ARGB Connector |
5V ARGB 3-PIN Header |
|
Radiator Base Material |
CPU Direct Contact [C.D.C.] |
|
Radiator Dimensions |
152 × 121 × 94.5 mm |
|
Radiator Material |
AL1100 + AL6063 + C1020 |
|
Radiator FIN |
50PCS |
|
Radiator Heat-pipe SPEC |
Φ6mm / 4PCS |
|
Intel Socket |
LGA 1700 / 1851 |
|
AMD Socket |
AM5 / AM4 |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
SPECIFICATION
|
Number of Fans |
1 |
|
Fan Dimensions |
120 x 120 x 25 mm / 4.7 x 4.7 x 0.98 inches |
|
Fan Speed |
510~2070 RPM ± 200 RPM (10%) |
|
Fan Air Flow |
62.6 CFM |
|
Fan Noise Level |
30.11 dBA (MAX 34.1) |
|
Fan Static Pressure |
2.36 mmH₂O |
|
Fan Bearing |
Rifle Bearing |
|
Fan Life Expectancy |
40,000 hrs @ 40℃ |
|
Fan Rated Current |
0.15A (Max: 0.18A) |
|
Fan Power Consumption |
1.44W (Max: 2.16W) |
|
PWM Mode |
Yes |
|
Cable Length (5V ARGB / PWM cable) |
300mm |
|
Fan Lighting |
ARGB GEN1 |
|
ARGB Connector |
5V ARGB 3-PIN Header |
|
Radiator Base Material |
CPU Direct Contact [C.D.C.] |
|
Radiator Dimensions |
152 × 121 × 94.5 mm |
|
Radiator Material |
AL1100 + AL6063 + C1020 |
|
Radiator FIN |
50PCS |
|
Radiator Heat-pipe SPEC |
Φ6mm / 4PCS |
|
Intel Socket |
LGA 1700 / 1851 |
|
AMD Socket |
AM5 / AM4 |
