SPECIFICATION
|
Product No. |
SST-ST50F-ES230 |
|
Max. DC Output |
500W |
|
Power Density |
277W per liter |
|
Load Range |
Output |
|
+3.3V +5V +12V +5VSB -12V |
|
|
Max. (Amps) |
18A 17A 38A 2.5A 0.3A |
|
Peak (Amps) |
/ / / / / |
|
Min. (Amps) |
0A 0A 0A 0A 0A |
|
Range (%) |
±5% ±5% ±5% ±5% ±10% |
|
Line Reg. (%) |
±1% ±1% ±1% ±1% ±1% |
|
Ripple (mVp-p) |
50mV 50mV 120mV 50mV 120mV |
|
Combined +3.3V & +5V |
110W |
|
Combined +12V |
456W |
|
Input Voltage |
180 ~ 264Vrms |
|
Input Frequency Range |
47Hz ~ 63Hz |
|
PFC |
Active PFC (PF>0.9 at Full Load) |
|
Efficiency |
82%~85% @ 20% ~ 100% loading |
|
MTBF |
100,000 hours |
|
Operating Temperature |
0°C ~ 40°C |
|
Protection |
Over power protection |
|
Over voltage protection |
|
|
Short circuit protection |
|
|
Connectors |
1 x 24 / 20-Pin motherboard connector (500mm) |
|
1 x 8 / 4-Pin EPS / ATX 12V connector (750mm) |
|
|
2 x 8 / 6-Pin PCIE connector ("500mm / 150mm") |
|
|
2 x SATA connector and |
|
|
1 x 4-Pin Peripheral connector and |
|
|
1 x 4-Pin Floppy connector ("500mm / 150mm / 150mm / 150mm") |
|
|
2 x SATA connector and |
|
|
2 x 4-Pin Peripheral connector ("500mm / 150mm / 150mm / 150mm") |
|
|
Cooling System |
Silent 120mm fan |
|
Noise Level |
18 dBA minimum |
|
Certification |
80 PLUS |
|
Dimension |
150 mm (W) x 86 mm (H) x 140 mm (D) |
|
Weight |
1.31kg |
|
Other |
GPU Support list |
