Original: $42.69
-70%$42.69
$12.81The Story
SPECIFICATION
|
Product No. |
SST-ST60F-ES230 (80 PLUS) |
|
Color |
Black (Lead-Free Paint) |
|
Max. DC Output |
600W |
|
Power density |
332W per liter |
|
Load Range |
+3.3V, +5V, +12V, +5VSB, -12V |
|
Max. Amps |
20A, 20A, 46A, 2.5A, 0.3A |
|
Peak Amps |
N/A |
|
Min. Amps |
0A, 0A, 0A, 0A, 0A |
|
Range (%) |
±5% for +3.3V, +5V; ±5% for +12V; ±5% for +5VSB; ±10% for -12V |
|
Line Reg. (%) |
±1% for all outputs |
|
Ripple (mVp-p) |
50mV for +3.3V, +5V; 120mV for +12V, +5VSB; 120mV for -12V |
|
Combined +3.3V & +5V |
120W |
|
Combined +12V |
552W |
|
Input Voltage |
180V~264V |
|
Input Frequency Range |
47Hz~63Hz |
|
PFC |
Active PFC (PF > 0.9 at full load) |
|
Efficiency |
82% ~ 85% at 20% ~ 100% loading |
|
MTBF |
100,000 hours |
|
Operating temperature |
0°C ~ 40°C |
|
Protection |
Over power protection, Over voltage protection, Short circuit protection |
|
Connectors |
See detailed list in the description |
|
Cooling System |
Single 120mm silent fan |
|
Noise Level |
18 dBA minimum |
|
Certification |
80 PLUS |
|
Form factor |
ATX |
|
Dimension |
150mm (W) x 86mm (H) x 140mm (D) |
|
Weight |
1.41 kg |
|
Other |
GPU Support list |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
SPECIFICATION
|
Product No. |
SST-ST60F-ES230 (80 PLUS) |
|
Color |
Black (Lead-Free Paint) |
|
Max. DC Output |
600W |
|
Power density |
332W per liter |
|
Load Range |
+3.3V, +5V, +12V, +5VSB, -12V |
|
Max. Amps |
20A, 20A, 46A, 2.5A, 0.3A |
|
Peak Amps |
N/A |
|
Min. Amps |
0A, 0A, 0A, 0A, 0A |
|
Range (%) |
±5% for +3.3V, +5V; ±5% for +12V; ±5% for +5VSB; ±10% for -12V |
|
Line Reg. (%) |
±1% for all outputs |
|
Ripple (mVp-p) |
50mV for +3.3V, +5V; 120mV for +12V, +5VSB; 120mV for -12V |
|
Combined +3.3V & +5V |
120W |
|
Combined +12V |
552W |
|
Input Voltage |
180V~264V |
|
Input Frequency Range |
47Hz~63Hz |
|
PFC |
Active PFC (PF > 0.9 at full load) |
|
Efficiency |
82% ~ 85% at 20% ~ 100% loading |
|
MTBF |
100,000 hours |
|
Operating temperature |
0°C ~ 40°C |
|
Protection |
Over power protection, Over voltage protection, Short circuit protection |
|
Connectors |
See detailed list in the description |
|
Cooling System |
Single 120mm silent fan |
|
Noise Level |
18 dBA minimum |
|
Certification |
80 PLUS |
|
Form factor |
ATX |
|
Dimension |
150mm (W) x 86mm (H) x 140mm (D) |
|
Weight |
1.41 kg |
|
Other |
GPU Support list |
