SILVERSTONE Triton 850Rx 850W Cybenetics 80+ Gold Non-Modular Power Supply

Product No.

SST-TR850R-GF

Model (Safety Certification)

SST-AX0850FCGD-A

Color

Black (lead-free paint)

Max. DC Output

850W

Power Density

470.7 W/L

Load Range – Output Rails

+3.3V / +5V / +12V1 / +5VSB / -12V

Max. Current (Amps)

18A / 18A / 70.8A / 3.0A / 0.3A

Min. Current (Amps)

0A / 0A / 0A / 0A / 0A

Voltage Range (%)

±5% / ±5% / ±5% / ±5% / ±10%

Line Regulation (%)

±1% / ±1% / ±1% / ±1% / ±1%

Ripple (mVp-p)

50mV / 50mV / 120mV / 50mV / 120mV

Combined +3.3V & +5V

100W

Combined +12V

850W

Input Voltage

90 ~ 264 Vrms

Input Frequency Range

47Hz ~ 63Hz

PFC (Power Factor Correction)

Active PFC (PF > 0.9 at full load)

Efficiency

87% ~ 89% overall efficiency

MTBF

100,000 hours

Operating Temperature

0°C ~ 40°C

Protection Features

Over power, Over current, Over voltage,
Short circuit, Under voltage, Over temperature

Connectors

1 × 24 / 20-Pin motherboard
2 × 8 / 4-Pin EPS / ATX 12V
1 × 12+4-Pin 12V-2x6
5 × 8 / 6-Pin PCIe
6 × SATA
2 × 4-Pin Peripheral

Cooling System

Single 120mm ICB bearing fan

Noise Level

18 dBA min.

Certification

Cybenetics Gold

Form Factor

ATX (PS2)

Dimensions (Metric)

150mm (W) × 86mm (H) × 140mm (D)

Dimensions (Imperial)

5.91" (W) × 3.39" (H) × 5.51" (D)

Weight

1.56 kg
