TP-LINK Archer Air R5 AX3000 Dual-Band Wi-Fi 6 Air Router

Network Security

- HomeShield Security

- Real-Time IoT Protection

- Malicious Site Blocker

- Intrusion Prevention System

- DDoS Attack Prevention

- Home Network Scanner

Guest Network

- 1× 5 GHz Guest Network

- 1× 2.4 GHz Guest Network

VPN Server

- PPTP Server (N)

- OpenVPN Server (N)

WiFi Encryption

- WPA/WPA2

- WPA3

- WPA/WPA2-PSK

Wireless Standards

- Wi-Fi 6

- IEEE 802.11ax/ac/n/a 5 GHz

- IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds

- AX3000

- 5 GHz: 2402 Mbps (802.11ax, HE160)

- 2.4 GHz: 574 Mbps (802.11ax)

WiFi Range

- 3 Bedroom Houses

- Multiple antennas for signal-boosting array

- Beamforming (Concentrates signal strength)

- High-Power FEM (Improves transmission power)

WiFi Capacity

- High

- Dual-Band

- OFDMA

- Airtime Fairness

- 4 Streams

Working Modes

- Router Mode

- AP Mode

Hardware Features

- 1× Gigabit WAN Port

- 1× Gigabit LAN Port

- WPS Button

- Reset Button

Software

- IPv4

- IPv6

Mesh Technology

- EasyMesh-Compatible

Parental Controls

- HomeShield Parental Controls

- Custom Profiles

- Professional Content Filter Library

- Family Time

- Bedtime

- Off Time

- Time Rewards

- Family Online Time Ranking

- Pause the Internet

- Weekly and Monthly Reports

WAN Types

- Dynamic IP

- Static IP

- PPPoE

- PPPoE + Dynamic IP

- PPPoE + Static IP

- L2TP + Dynamic IP

- L2TP + Static IP

- PPTP + Dynamic IP

- PPTP + Static IP

Quality of Service

- QoS by Device

Cloud Service

- FOTA Firmware Upgrade

- TP-Link ID

- DDNS

NAT Forwarding

- Port Forwarding

- Port Triggering

- DMZ

- UPnP

IPTV

- Profile

- Bridge

- Custom

- Allowed range of VLAN ID

DHCP

- DHCP Server

- Address Reservation

- DHCP Client List

DDNS

- TP-Link

- NO-IP

- DynDNS

Management

- Tether App

- Webpage

- Check Web Emulator

System Requirements

- Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

- Cable or DSL Modem (if needed)

- Subscription with an internet service provider (for internet access)

Certifications

- FCC

- CE

- RoHS

Environment

- Operating Temperature: 0℃~40℃ (32℉ ~104℉)

- Storage Temperature: -40~60℃

- Operating Humidity: 10%~90% non-condensing

- Storage Humidity: 5%~90%

Test Data

- WiFi Transmission Power: CE (<20dBm, <23dBm, <30dBm), FCC (<30dBm)

- WiFi Reception Sensitivity (various bands)

Physical Dimensions

- 8.3 × 5.5 × 0.4 in (210 × 140 × 10.8 mm)

Package Contents

- Wireless Router Archer Air R5

- Quick Installation Guide

- Power Adapter

- Plastic Bracket

- Gigabit Network Cable

- Installation Accessories
