The Story
SPECIFICATION
|
Standards |
- Wi-Fi 6 (IEEE 802.11ax) |
|
- IEEE 802.11ax/ac/n/a (5 GHz) |
|
|
- IEEE 802.11ax/n/b/g (2.4 GHz) |
|
|
WiFi Speeds |
- AX5400 |
|
- 5 GHz: 4804 Mbps (802.11ax, HE160) |
|
|
- 2.4 GHz: 574 Mbps (802.11ax) |
|
|
WiFi Range |
- 3 Bedroom Houses |
|
- 6× Fixed High-Performance Antennas |
|
|
- Beamforming |
|
|
- High-Power FEM |
|
|
- 4T4R |
|
|
WiFi Capacity |
- High |
|
- Dual-Band |
|
|
- 4×4 MU-MIMO |
|
|
- OFDMA |
|
|
- Airtime Fairness |
|
|
- DFS |
|
|
- 6 Streams |
|
|
Working Modes |
- Router Mode |
|
- Access Point Mode |
|
|
Security |
- SPI Firewall |
|
- Access Control |
|
|
- IP & MAC Binding |
|
|
- Application Layer Gateway |
|
|
- HomeShield Security |
|
|
- Real-Time IoT Protection |
|
|
- Malicious Site Blocker |
|
|
- Intrusion Prevention System |
|
|
- DDoS Attack Prevention |
|
|
- Home Network Scanner |
|
|
Guest Network |
- 1× 5 GHz Guest Network |
|
- 1× 2.4 GHz Guest Network |
|
|
VPN Server |
- OpenVPN |
|
- PPTP |
|
|
VPN Client |
- Open VPN Client |
|
- PPTP VPN Client |
|
|
- L2TP VPN Client |
|
|
WiFi Encryption |
- WPA |
|
- WPA2 |
|
|
- WPA3 |
|
|
- WPA/WPA2-Enterprise (802.1x) |
|
|
Hardware |
- Processor: 1 GHz Dual-Core CPU |
|
- Ethernet Ports: 1× Gigabit WAN Port, 4× Gigabit LAN Ports |
|
|
- USB Support: 1× USB 3.0 Port |
|
|
- Supported Partition Formats: NTFS, exFAT, HFS+, FAT32 |
|
|
- Supported Functions: Apple Time Machine, FTP Server, Media Server, Samba Server |
|
|
- Buttons: Wi-Fi On/Off, Power On/Off, LED On/Off, WPS, Reset |
|
|
- Power: 12 V ⎓ 2.5 A |
|
|
Software |
- Protocols: IPv4, IPv6 |
|
- Service Kits: HomeShield |
|
|
- OneMesh™ Supported |
|
|
- Parental Controls: Custom Profiles, Professional Content Filter Library, Family Time, Bedtime, Off Time, Time Rewards, etc. |
|
|
- WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP |
|
|
- Quality of Service: QoS by Device |
|
|
- Cloud Service: Auto Firmware Upgrade, TP-Link ID, DDNS |
|
|
- NAT Forwarding: Port Forwarding, Port Triggering, DMZ, UPnP, Virtual Server |
|
|
- IPTV: IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN |
|
|
- DHCP: Address Reservation, DHCP Client List, Server |
|
|
- DDNS: TP-Link, NO-IP, DynDNS |
|
|
- Management: Tether App, Webpage |
|
|
System Requirements |
- Browser: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser |
|
- Cable or DSL Modem (if needed) |
|
|
- Subscription with an internet service provider (for internet access) |
|
