TP-LINK Archer T3U Plus AC1300 High Gain Wireless Dual Band USB Adapter

HARDWARE FEATURES

Interface

USB 3.0

LED

Status

Dimensions

2.28 × 0.71 × 6.83 in (57.8 × 18 × 173.4 mm)

Antenna

2 External High Gain Antennas

WIRELESS FEATURES

Wireless Standards

- IEEE 802.11b/g/n 2.4 GHz

- IEEE 802.11a/n/ac 5 GHz

Signal Rate

- 5 GHz:

- 11ac: Up to 867 Mbps(dynamic)

- 11n: Up to 300 Mbps(dynamic)

- 11a: Up to 54 Mbps(dynamic)

- 2.4 GHz:

- 11n: Up to 400 Mbps(dynamic)

- 11g: Up to 54 Mbps(dynamic)

- 11b: Up to 11 Mbps(dynamic)

Reception Sensitivity

- 5 GHz:

- 11ac VHT80: -62dBm

- 11ac VHT40: -64dBm

- 11ac VHT20: -68dBm

- 11n HT40: -71dBm

- 11n HT20: -73dBm

- 11a 54Mbps: -77dBm

- 2.4 GHz:

- 11n HT40: -70dBm

- 11n HT20: -71dBm

- 11g 54Mbps: -73dBm

- 11b 11Mbps: -87dBm

Transmit Power

- 5 GHz:

- 20dBm(FCC) / 20dBm(CE) (EIRP)

- 2.4 GHz:

- 18dBm(FCC) / 18dBm(CE) (EIRP)

Wireless Modes

- Infrastructure mode

Wireless Security

- WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

OTHERS

Certification

- FCC, CE, RoHS

Package Contents

- AC1300 High Gain Wireless Dual Band USB Adapter

- Quick Installation Guide

- Resource CD

System Requirements

- Windows 10/8.1/8/7 (32/64 bit)

Environment

- Operating Temperature: 0℃~40℃ (32℉ ~104℉)

- Storage Temperature: -40℃~70℃ (-40℉ ~158℉)

- Operating Humidity: 10%~90% non-condensing

- Storage Humidity: 5%~90% non-condensing
