TP-LINK VIGI NVR1104H-4P NVR KIT

Resolution

2 MP (1920 × 1080)

2 MP (1920 × 1080)

Supports up to 8 MP input; decodes 2 channels @ 8 MP or 4 channels @ 4 MP

Lens Options

Fixed, 2.8 mm (f/2.2) or 4 mm (f/2.0)

Fixed, 2.8 mm, 4 mm, or 6 mm (f/2.2 for 2.8 mm; f/2.0 for 4/6 mm)

N/A

Field of View (Diagonal)

2.8 mm: 106.5°; 4 mm: 88.1°

2.8 mm: 106.5°; 4 mm: ~88°; 6 mm: 56°

N/A

IR/Night Vision

IR LED, 30 m range, 850 nm

IR LED, 30 m range

N/A

Smart Detection & AI

Human & vehicle classification; Smart Detection – line-crossing, intrusion, object removal/abandonment

Same – human/vehicle classification, smart detection modes

N/A

Video Compression

H.265+/H.265/H.264+/H.264

H.265+/H.265/H.264+/H.264

Supports H.265+/H.265/H.264+/H.264 decoding & record processing

Weatherproof Rating

IP67

IP67

N/A

Power / Connectivity

PoE (802.3af/at, Class 0) or 12 V DC; RJ-45 network port

PoE (802.3af/at, Class 0) or 12 V DC; RJ-45 network port

4× PoE+ ports (802.3af/at), 53 W total budget, Gig RJ-45 10/100 Mbps

Storage and Playback

N/A

N/A

1 × SATA (up to 10 TB); simultaneous playback: up to 4 channels; 4K HDMI + VGA outputs

Dimensions

Not specified

174 × 74 × 71 mm

200.3 × 200.3 × 43 mm

Operating Temp.

Not specified

–30 °C to 60 °C

–10 °C to 55 °C

Key Features

Corridor Mode; Enhanced video (WDR, 3D DNR, Smart IR), PoE, ONVIF, flexible management

SmartVid enhancements (WDR, 3D DNR, Smart IR), PoE, ONVIF, AI classification, robust housing

Plug & Play camera auto-add, H.265+ smart compression, remote monitoring, built-in speaker
