SPECIFICATION
|
Mechanical |
|
|
Dimensions |
Ø197 x 35 mm (Ø7.8 x 1.4") |
|
Weight |
Without mount: 580 g (1.3 lb) / With mount: 720 g (1.6 lb) |
|
Enclosure Material |
Polycarbonate |
|
Mount Material |
Stainless steel (SUS304) |
|
Weatherproofing |
IP54 |
|
Hardware |
|
|
Networking Interface |
(1) GbE RJ45 port |
|
Management Interface |
Ethernet, Bluetooth |
|
Power Method |
PoE |
|
Power Supply |
UniFi PoE switch, PoE adapter (Not included) |
|
Supported Voltage Range |
44—57V DC |
|
Max. Power Consumption |
13W |
|
Max. TX Power |
|
|
2.4 GHz |
22 dBm |
|
5 GHz |
26 dBm |
|
6 GHz |
– |
|
MIMO |
|
|
2.4 GHz |
2 x 2 (UL MU-MIMO) |
|
5 GHz |
4 x 4 (DL/UL MU-MIMO) |
|
6 GHz |
– |
|
Max. Data Rate |
|
|
2.4 GHz |
573.5 Mbps (BW40) |
|
5 GHz |
4.8 Gbps (BW160) |
|
6 GHz |
– |
|
Antenna Gain |
|
|
2.4 GHz |
4 dBi |
|
5 GHz |
6 dBi |
|
6 GHz |
– |
|
LEDs |
White/blue |
|
Button |
Factory reset |
|
Mounting |
Wall, ceiling (Included) |
|
Ambient Operating Temp |
-30 to 60° C (-22 to 140° F) |
|
Ambient Operating Hum. |
5 to 95% noncondensing |
|
Certifications |
CE, FCC, IC |
|
Software |
|
|
WiFi Standards |
802.11a/b/g/n/ac/ax (WiFi 6) |
|
Wireless Security |
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
|
BSSID |
8 per radio |
|
VLAN |
802.1Q |
|
Advanced QoS |
Per-user rate limiting |
|
Guest Traffic Isolation |
Supported |
|
Concurrent Clients |
350+ |
|
Zero Wait DFS |
Yes* |
|
* |
Supported with upcoming firmware versions |
|
Supported Data Rates |
|
|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|
802.11b |
1, 2, 5.5, 11 Mbps |
|
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|
802.11n |
6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) |
|
802.11ac |
6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) |
|
802.11ax (WiFi 6) |
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) |
|
Application Requirements |
UniFi Network Version 6.1.56 and later |
