SPECIFICATION
|
Mechanical |
|
|
Dimensions |
150 x 103 x 36 mm (5.9 x 4.1 x 1.4") |
|
Weight |
580 g (1.3 lb) |
|
Enclosure Material |
Polycarbonate, aluminum |
|
Mount Material |
Aluminum |
|
Hardware |
|
|
Networking Interface |
(1) 1/2.5 GbE RJ45 port |
|
Management Interface |
Ethernet |
|
Power Method |
PoE+ |
|
Power Supply |
UniFi PoE switch |
|
Supported Voltage |
44—57V DC |
|
Max. Power Consumption |
22W |
|
Max. TX Power |
|
|
2.4 GHz |
22 dBm |
|
5 GHz |
26 dBm |
|
6 GHz |
23 dBm |
|
MIMO |
|
|
2.4 GHz |
2 x 2 (DL/UL MU-MIMO) |
|
5 GHz |
2 x 2 (DL/UL MU-MIMO) |
|
6 GHz |
2 x 2 (DL/UL MU-MIMO) |
|
Max. Data Rate |
|
|
2.4 GHz |
688 Mbps (BW40) |
|
5 GHz |
4.3 Gbps (BW240) |
|
6 GHz |
5.7 Gbps (BW320) |
|
Antenna Gain |
|
|
2.4 GHz |
4 dBi |
|
5 GHz |
5 dBi |
|
6 GHz |
6 dBi |
|
LEDs |
White/blue |
|
Button |
Factory reset |
|
Mounting |
Wall (Included), Table stand, flush mount (Optional) |
|
Ambient Operating Temp |
-30 to 60° C (-22 to 140° F) |
|
Ambient Operating Hum. |
5 to 95% noncondensing |
|
Certifications |
CE, FCC, IC |
|
Software |
|
|
WiFi Standards |
802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7) |
|
Wireless Security |
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
|
BSSID |
8 per radio |
|
VLAN |
802.1Q |
|
Advanced QoS |
Per-user rate limiting |
|
Guest Traffic Isolation |
Supported |
|
Concurrent Clients |
300+ |
|
Supported Data Rates |
|
|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|
802.11b |
1, 2, 5.5, 11 Mbps |
|
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|
802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
|
802.11ac |
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
|
802.11ax (WiFi 6/6E) |
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
|
802.11be (WiFi 7) |
7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320) |
|
Application Requirements |
UniFi Network Version 8.1 and later / UniFi OS Version 3.2 and later |
