SPECIFICATION
|
Mechanical |
|
|
Dimensions |
442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
|
Weight |
4.7 kg (10.4 lb) |
|
Enclosure Material |
Aluminium CNC, SGCC steel |
|
Mount Material |
SGCC steel |
|
Hardware |
|
|
Processor |
Quad-core ARM® Cortex®-A57 at 2.0 GHz |
|
System Memory |
8 GB DDR4 |
|
On-board Storage |
32 GB eMMC |
|
Integrated SSD |
128 GB |
|
Management Interface |
Ethernet, Bluetooth |
|
Networking Interface |
|
|
LAN |
(8) GbE RJ45 ports, (1) 10G SFP+ port |
|
WAN |
(1) 2.5 GbE RJ45 port, (1) 10G SFP+ port |
|
IDS/IPS Throughput |
5 Gbps* (Measured with iPerf3 on a DHCP network) |
|
Power |
|
|
Power Method |
Universal AC input (100—240V AC, 2A Max., 50/60 Hz), USP-RPS DC input (11.5V DC, 8.7A) |
|
Power Supply |
AC/DC, internal, 100W |
|
Supported Voltage Range |
100—240V AC |
|
Max Power Consumption |
60W |
|
Environmental |
|
|
ESD/EMP Protection |
Air: ±15kV, Contact: ±8kV |
|
Ambient Temperature |
-10° to 40° C (14° to 104° F) |
|
Ambient Humidity |
5 to 95% noncondensing |
|
Certifications |
CE, FCC, IC |
|
Gateway Features |
|
|
Performance |
Redundant WAN with failover/load balancing, WiFi QoS with UniFi APs, app/device type identification |
|
Security |
Application-aware firewall, IPS/IDS threat detection, filtering (content, domain, country, ad) |
|
Networking |
License-free SD-WAN, WireGuard, OpenVPN, site-to-site VPN, DHCP relay, IPv6 ISP support |
|
LED Indicators |
|
|
Ethernet |
Green: link/activity |
|
SFP+ |
Green: link/activity |
|
HDD |
White: disk activity, Amber: disk error |
|
RPS |
Blue: ready |
|
Other Features |
1.3" touchscreen display, Factory reset button |
