SPECIFICATION
|
Model Name |
27B36H3 |
|
Panel |
27" / IPS |
|
Pixel Pitch (mm) |
0.3114 (H) × 0.3114 (V) |
|
Effective Viewing Area (mm) |
597.88 (H) × 336.31 (V) |
|
Brightness (typical) |
250 cd/m² |
|
Contrast Ratio |
1500 : 1 (typical) / Mega DCR |
|
Response Time |
4 ms GtG / 1 ms MPRT |
|
Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
|
Color Gamut |
NTSC 91% (CIE1976) / sRGB 104% (CIE1931) |
|
Color Accuracy |
– |
|
Optimum Resolution |
1920 × 1080 @ 100 Hz (HDMI); 1920 × 1080 @ 75 Hz (VGA) |
|
Display Colors |
16.7 Million |
|
Signal Input |
VGA × 1, HDMI 1.4 × 1 |
|
HDCP Version |
– |
|
USB Hub |
No |
|
Power Supply |
External 19 V DC, 1.31 A |
|
Power Consumption (typical) |
20 W |
|
Speakers |
No |
|
Line In & Earphone |
No |
|
Wall-Mount |
100 mm × 100 mm |
|
Adjustable Stand |
Tilt: –5° ~ 23° |
|
Product without Stand (mm) |
356.7 (H) × 616.6 (W) × 37.4 (D) |
|
Product with Stand (mm) |
445.5 (H) × 616.6 (W) × 205.6 (D) |
|
Packaging (mm) |
447 (H) × 690 (W) × 103 (D) |
|
Product without Stand (kg) |
3.1 kg |
|
Product with Stand (kg) |
3.4 kg |
|
Product with Packaging (kg) |
5.3 kg |
|
Cabinet Color |
Black |
|
Regulatory Approvals |
CE / FCC |
