ASROCK B550M Pro4 mATX Motherboard

USB 3.2 Gen2

- Type-A Port (10 Gb/s)

- Type-C Port (10 Gb/s)

Super Alloy

- XXL Aluminum Alloy Heatsink

- Premium 50A Power Choke

- Sapphire Black PCB

- High Density Glass Fabric PCB

- 2oz Copper PCB

Steel Slot Gen4

- Enhanced durability and stability for PCIe slots

Full Coverage M.2 Heatsink

- Efficient cooling for M.2 SSDs

Hyper M.2 (PCIe Gen4x4)

- Supports high-speed PCIe Gen4x4 SSDs

POST Status Checker (PSC)

- Easy debugging with status LEDs

Full Spike Protection

- Comprehensive protection for all USB, audio, and LAN ports

Live Update & APP Shop

- Convenient software updates and downloads

CPU Support

- AMD AM4 Socket Ryzen™ 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors

- Digi Power design

- 8 Power Phase design

Chipset

- AMD B550

Memory

- Dual Channel DDR4 Memory Technology

- 4 x DDR4 DIMM Slots

- Supports various DDR4 speeds up to 4733+(OC) depending on the CPU/APU

- Max. capacity: 128GB

- Supports Extreme Memory Profile (XMP) memory modules

- 15μ Gold Contact in DIMM Slots

BIOS

- 256Mb AMI UEFI Legal BIOS with GUI support

- Supports "Plug and Play"

- ACPI 5.1 compliance wake up events

- Supports jumperfree

- SMBIOS 2.3 support

- Voltage Multi-adjustment options

Graphics

- Integrated AMD Radeon™ Vega Series Graphics in Ryzen Series APU

- DirectX 12, Pixel Shader 5.0

- Supports Triple Monitor

- Supports resolutions up to 5K (5120x2880)@120Hz

- Supports HDR and HDCP 2.3

- Supports 4K Ultra HD playback

Audio

- 7.1 CH HD Audio with Content Protection (Realtek ALC1220/ALC1200 Audio Codec)

- Premium Blu-ray Audio support

- Supports Surge Protection

- PCB Isolate Shielding

- Nahimic Audio

LAN
