SPECIFICATION
|
Picture/Display |
|
|
Panel Size |
27"/68.6cm |
|
Aspect Ratio |
16:9 |
|
LCD Panel Type |
IPS technology |
|
Backlight Type |
W-LED system |
|
Pixel Pitch |
0.3114 x 0.3114 mm |
|
Brightness |
300 cd/m² |
|
Display Colors |
16.7 M |
|
Contrast Ratio (Typical) |
1500:1 |
|
SmartContrast |
Mega Infinity DCR |
|
Response Time (Typical) |
4 ms (Gray to Gray)* |
|
Viewing Angle |
178º (H) / 178º (V) @ C/R > 10 |
|
Picture Enhancement |
SmartImage |
|
Maximum Resolution |
1920 x 1080 @ 120 Hz |
|
Effective Viewing Area |
597.888(H) x 336.312(V) mm |
|
Scanning Frequency |
VGA: 30 KHz - 85 KHz (H) / 48 Hz - 75 Hz (V); HDMI: 30 KHz - 140 KHz (H) / 48 Hz - 120 Hz (V) |
|
sRGB |
Yes |
|
Flicker-Free |
Yes |
|
Pixel Density |
82 PPI |
|
LowBlue Mode |
Yes |
|
Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
|
MPRT |
1 ms* |
|
EasyRead |
Yes |
|
Adaptive Sync |
Yes |
|
Connectivity |
|
|
Signal Input |
VGA x 1, HDMI 1.4 x 1 |
|
Sync Input |
Separate Sync, Sync on Green |
|
HDCP |
HDCP 1.4 (HDMI) |
|
Convenience |
|
|
Plug & Play Compatibility |
DDC/CI |
|
Mac OS X |
sRGB |
|
Windows 11 / 10 |
Yes |
|
User Convenience |
Power On/Off, Menu, Brightness, Input, SmartImage |
|
OSD Languages |
Brazil Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian |
|
Other Convenience |
Kensington lock, VESA mount (100x100mm) |
|
Stand |
|
|
Tilt |
-5/20 degrees |
|
Power |
|
|
Power Supply |
External, 100-240VAC, 50-60Hz |
|
Off Mode |
0.3 W (typ.) |
|
On Mode |
16.8 W (typ.) |
|
Standby Mode |
0.5 W (typ.) |
|
Power LED Indicator |
Operation - White; Standby - White (blinking) |
|
Dimensions |
|
|
Packaging (WxHxD, mm) |
690 x 480 x 124 mm |
|
Product without Stand (mm) |
616 x 359 x 33 mm |
|
Product with Stand (max height) |
616 x 454 x 200 mm |
|
Weight |
|
|
Product with Packaging |
5.56 kg |
|
Product with Stand |
3.22 kg |
|
Product without Stand |
2.85 kg |
|
Operating Conditions |
|
|
Altitude |
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
|
Temperature Range (Operation) |
0 to 40 °C |
|
MTBF |
50,000 hrs (excluding backlight) |
|
Relative Humidity |
20% - 80% |
|
Temperature Range (Storage) |
-20 to 60 °C |
|
Sustainability |
|
|
Environmental & Energy |
RoHS |
|
Recyclable Packaging Material |
100% |
|
Specific Substances |
PVC / BFR free housing |
|
Compliance and Standards |
|
|
Regulatory Approvals |
CB, CE Mark, ETL, CEC, PSE, CEL, CCC, CECP, BSMI, VCCI, UKCA, EMF, FCC, ICES-003 |
|
Cabinet |
|
|
Color |
Black |
|
Finish |
Textured |
